SpecificationS
1-4 powermax 45 Service Manual
Power supply ratings
Rated open-circuit voltage (U
0
)
CSA/CE, single-phase
CE, 3-phase
CSA, 3-phase
275VDC (CSA/CE single-phase)
275VDC (CE 3-phase)
278VDC (CSA 3-phase)
Rated output current (I
2
) 20 A to 45 A
Rated output voltage (U
2
) 132VDC
Duty cycle at 40° C
(See data plate on power supply for moreinformation on
dutycycle.)
50% (I
2
=45 A, U
2
=132V)
60% (I
2
=41 A, U
2
=132V)
100% (I
2
=32 A, U
2
=132V)
Operating temperature -10° to 40° C (14° to 104° F)
Storage temperature -25° to 55° C (-13° to 131° F)
Power factor
200–240V CSA, 230V CE, 1-phase
400V CE, 3-phase
480V CSA, 3-phase
0.99
0.94
0.93
Input voltage (U
1
) / Input current (I
1
) at
ratedoutput(U
2MAX
,I
2MAX
)
(See Voltage configurations in the Power Supply Setup
section for more information.)
200–240VAC / 34–28 A (200–240V CSA)
230VAC / 30 A (230V CE)*
400VAC / 10 A (400V CE)**
480VAC / 8.5A (480V CSA)
Gas type Air Nitrogen
Gas quality Clean, dry, oil-free per ISO
8573-1 Class 1.2.2
99.995% pure
Recommended gas inlet flow and pressure 170 l/min at 6.2 bar (360 scfh at 90 psi)
* Equipment complies with IEC 61000-3-12.
** Equipment complies with IEC 61000-3-12 provided that the short-circuit power S
sc
is greater than or equal to
692KVA at the interface point between the user’s supply and the public system. It is the responsibility of the installer
or user of the equipment to ensure, by consultation with the distribution network operator if necessary, that the
equipment is connected only to a supply with a short-circuit power S
sc
greater than or equal to 692 KVA.
