SpecificationS
1-6 powermax
45
Service Manual
T45v and T45m torch specifications
Handheld cut capacity (material thickness)
Recommended cut capacity (hand cutting) 12.7 mm (1/2 inch)
Maximum cut capacity (hand cutting or mechanized
edgestart)
19.1 mm (3/4 inch)
Severance capacity (hand cutting or mechanized edgestart) 25.4 mm (1 inch)
Mechanized pierce capacity (material thickness)
Pierce capacity
(for edge starts, the capacities are the same as the handheld
capacities)
9.5 mm (3/8 inch)
Recommended cut speed (on mild steel)
6.35 mm (1/4 inch) 1524 mm/min (60 ipm)
9.53 mm (3/8 inch) 813 mm/min (32 ipm)
12.7 mm (1/2 inch) 508 mm/min (20 ipm)
19.1 mm (3/4 inch) 203 mm/min (8 ipm)
25.4 mm (1 inch) 102 mm/min (4 ipm)
Gouging capacity
Metal removal rate on mild steel 2.8 kg/hr (6.2 lbs/hr)
Weight
T45v torch only 0.27 kg (0.6 lb)
T45v with 6.1 m (20 foot) lead 1.55 kg (3.4 lb)
T45v with 15.24 m (50 foot) lead 3.54 kg (7.8 lb)
T45m torch only 0.45 kg (1.0 lb)
T45m with 7.62 m (25 foot) lead 2.27 kg (5.0 lb)
T45m with 10.7 m (35 foot) lead 2.90 kg (6.4 lb)
T45m with 15.24 m (50 foot) lead 3.85 kg (8.5 lb)
