powermax 45 Service Manual 2-5
Extension cord recommendations
Use an extension cord of an appropriate wire size for the cord length and system voltage. Usea cord that meets national
and local codes.
The following tables provide the recommended gauge size for various lengths and input voltages. The lengths in the
tables are the length of the extension cord only; they do not include the power supply’s power cord.
Metric
Input voltage Phase < 3 m 3–7.5 m 7.5–15 m 15–30 m 30 –45 m
208VAC 1 10 mm
2
10 mm
2
10 mm
2
16 mm
2
25 mm
2
220VAC
1
10 mm
2
10 mm
2
10 mm
2
16 mm
2
25 mm
2
200–240VAC
1
10 mm
2
10 mm
2
10 mm
2
16 mm
2
25 mm
2
380VAC
3
4 mm
2
4 mm
2
4 mm
2
6 mm
2
6 mm
2
400VAC
3
4 mm
2
4 mm
2
4 mm
2
6 mm
2
6 mm
2
480VAC
3
4 mm
2
4 mm
2
4 mm
2
6 mm
2
6 mm
2
English
Input voltage Phase < 10 feet 10–25 feet 25–50 feet 50–100 feet 100–150 feet
208VAC 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
220VAC 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
200–240VAC 1 8 AWG 8 AWG 8 AWG 6 AWG 4 AWG
380VAC 3 12 AWG 12 AWG 12 AWG 10 AWG 10 AWG
400VAC 3 12 AWG 12 AWG 12 AWG 10 AWG 10 AWG
480VAC 3 12 AWG 12 AWG 12 AWG 10 AWG 10 AWG
