Hypertherm powermax45 Service Manual

torch setup
3-14 powermax 45 Service Manual
T45m shielded consumables
Air flowrate (scfh)
Aluminum
Hot 320
English
Cold 360
Recommended Maximum
Arc
current
(amps)
Material
thickness
Torch-
to-work
distance
(in)
Initial pierce
height
Pierce time
delay
(sec)
Cut
Speed
(ipm)
Voltage
(V)
Cut
Speed
(ipm)
Voltage
(V)
30
0.018 in
(26 Ga)
0.06 0.15 in 250%
0.0 360 117 400* 120
0.060 in
(16 Ga)
0.2
340 118 400* 121
0.075 in
(14 Ga)
215 118 270 121
45
0.060 in
(16 Ga)
0.06
0.15 in 250%
0.0
360 116 400* 114
0.075 in
(14 Ga)
340 117 400* 116
0.105 in
(12 Ga)
280 120 360 119
0.135 in
(10 Ga)
0.1 220 122 280 120
0.188 in
(3/16 in)
0.2 100 123 130 120
0.250 in
(1/4 in)
0.3 80 123 100 120
0.375 in
(3/8 in)
0.5 33 130 42 125
0.500 in
(1/2 in)
Edge start recommended
20 134 25 130
0.750 in
(3/4 in)
8 143 10 138
*Maximum cut speed is limited by the test table’s maximum speed (400 ipm).
