Hypertherm powermax45 Service Manual

torch setup
powermax 45 Service Manual 3-17
T45m unshielded consumables
Air flowrate (lpm)
Stainless steel
Hot 151
Metric
Cold 165.2
Recommended Maximum
Arc
current
(amps)
Material
thickness
(mm)
Torch-
to-work
distance
(mm)
Initial pierce
height
Pierce time
delay
(sec)
Cut Speed
(mm/min)
Voltage
(V)
Cut Speed
(mm/min)
Voltage
(V)
30
0.5
2.0 5.0 mm 250%
0.0
9144 113 10160* 125
0.8 8128 115 10160* 128
0.9 7000 114 9000 125
1.5 0.2 3650 112 4800 118
45
0.9
2.0
5.0 mm 250%
0.0
8900 112 10160* 110
1.5 8100 115 10160* 113
1.9 0.1 7112 116 9144 114
2.7 0.3 4100 118 5080 116
3.4 0.4 2800 120 3556 118
4.8 0.5 1650 120 2032 118
6.4 0.6 1010 121 1270 118
9.5 0.8 610 125 762 120
12.7
Edge start recommended
355 130 457 126
19.1 175 133 229 138
*Maximum cut speed is limited by the test table’s maximum speed (10160 mm/min).
