HySecurity StrongArm 14F User Manual

MX3657-01 Rev. D ©2020 Display & Menu Options
hysecurity.com | 800-321-9947 71
Installer Menu Setting Options Menu Tasks & Explanations STC Wire
Connections
CB 0 (OFF)
CLD Disable ELD
0 = Normal operation of Free Exit
1 = Disable Free Exit
Setting 1 allows an CLD input to disable the
Free Exit Detector (ELD) until the barrier arm
is fully closed. Used in bi-directional trafc
situations.
Reset (Center)
Loop
COM or
connection to
HY-5A detector
EB 0 (OFF)
ELD Backoff
0 = Normal operation of Free Exit
1 = Back off close function
The default allows normal latch open
operation of the Free Exit detector. The
optional setting of 1, creates an automatic
close function if a vehicle triggers and then
backs off the Free Exit Loop detector.
Free Exit Loop
COM or
connection to
HY-5A detector
DL 1 STANDARD
DETECTOR LOGIC
1 = Standard
2 & 3 = Quick Close
4 = Full anti-tailgate
Determines how the operator responds to a
tail gate notication. See Anti-TailGate Mode
(Closing Logic) on page 93.
NOTE: Does not appear in barrier gate
operators.
RL 1 CLOSE LIM
RELAY 1 LOGIC
0 = Disabled
1 = Close limit active
(1 to 29 available)
Congures the function of the User 1 output
relay. It has the capacity to switch both AC
and DC loads and can be used for high
voltage and/or high current loads. Connect
devices directly to the top of the relay: COM
and either NO and/or NC contacts. Multiple
logic function options exist. Refer to User
Relays – Programming Procedure on page
81.
User 1 Relay
R2 6 GATE LOCK
RELAY 2 LOGIC
0 = Disabled
1 to 29 available
Congures the function of the User 2 output
relay. It has the capacity to switch both AC
and DC loads and can be used for high
voltage and/or high current loads. Connect
devices directly to the top of the relay: COM
plus NO and NC contacts. Multiple optional
logic function options exist. Refer to User
Relays – Programming Procedure on page
81.
User 2 Relay
R3 1 CLOSE LIM
RELAY 3 LOGIC
0 = Disabled
1 to 29 available
Relay 3 congures the function of the User
3 output relay, which is an electronic relay
with the capacity for switching a DC load
only. In the StrongArm M30/M50, Relay 3
is connected to the gate LED lighting and
does not appear as an option in the Installer
Menu.
User 3 Relay
R4 through R11
RELAY <n> LOGIC
0 = Disabled
1 to 29 available
Similar to Relay 1 Logic.
NOTE: The Hy8Relay
™
module option can
be purchased to provide an additional
8 relay terminals. Relay #39 set aside for
Factory Use.
COM
NOTE: R4
through RB user
relays appear
on 7-segment
display
TL 2 (45 SECS)
OPEN TIME ALERT
0 = 0s delay
1 = 15s
2 = 45 second delay
3 = 75s
4 = 105s
5 = 135s
Lets you specify when the relay activates.
The relay turns ON when the software
detects that the gate operator has been
off its close limit for the specied period of
time. With updated software versions, TL
appears in the Installer Menu even without
the User Relay option 8 being utilized.
User Relay 8
