Tuning Description
For details about tuning, please refer to the help file for appropriate tuner software supplied by us.
The test standard for current is described in the table below:
No. Test Item Test Value Test Condition
1 Power-off current Test value≤2mA
2 Mean stand-by current in TMO
(screen off)
140mA≤test value≤170mA
3
Mean stand-by current in DMO
(screen off)
210mA≤test value≤250mA
300mA≤test value≤650mA (the
antenna is connected.)
4
Mean TX current in DMO
(screen off)
300mA≤test value≤650mA (the
50Ω load is connected.)
Test v a lue ≤1900mA (the antenna
is connected.)
5
Max. TX current in DMO
(screen off)
Test v alu e ≤1800mA (the 50Ω
load is connected.)
300mA≤test value≤650mA (the
antenna is connected.)
6
Mean TX current in TMO
(screen off)
300mA≤test value≤650mA (the
50Ω load is connected.)
Test v a lue ≤1900mA (the antenna
is connected.)
7
Max. TX current in TMO
(screen off)
Test v alu e ≤1800mA (the 50Ω
load is connected.)
The voltage is 3.7V. Test
instrument and software:
Agilent power supply, GPIB
card, computer and current
test software.
