Service Manual
2. Remove the FPC
15 .
Disassembling the MMI Board
1. Pull out the FPC for keys
16 .
2. Pull out the speaker socket
17 .
3. Remove the board-to-board connector
18 .
4. Remove the two screws
19 .
5. Take the MMI board out
20 .
Disassembling the Encoder Switch
1. Remove the knob
21 .
