Hytera PT580 - PT580 F5 Parts List 2 (Main Board)

Service Manual
Parts List 2
PT580 F5 Parts List 2 (Main Board)
No. Ref. No. Print No. Part No. Description
1
A B2A 6201840000000 Heat sink
2
C1001 T4A 3101052000020 20PF
3
C1002 T4A 3101051040010 0.1UF
4
C1003 T4A 3101051040010 0.1UF
5
C1004 T4A 3101051040010 0.1UF
6
C1005 T4A 3101051040010 0.1UF
7
C1006 T4A 3101051040010 0.1UF
8
C1007 T4A 3101051040010 0.1UF
9
C1008 T3A 3101052490010 2.4PF
10
C1009 T3A 3101051290000 1.2PF
11
C1010 T4A 3101051010030 100PF
12
C1011 T4A 3101051010030 100PF
13
C1012 T4A 3101051010030 100PF
14
C1013 T4A 3101051010030 100PF
15
C1014 T4A 3101051010030 100PF
16
C1015 T3A 3101051030020 0.01UF
17
C1016 B2C 3101051010030 100PF
18
C1017 B2C 3101051010030 100PF
19
C1019 B2C 3101053690000 3.6PF
20
C1020 T3A 3101051800011 19PF
21
C1023 T2A 3101051010030 100PF
22
C1024 T4B 3101051220000 1200PF
23
C1025 T4B 3101071530000 0.015UF
24
C1026 T3B 3101056810010 680PF
25
C1027 T3B 3101051800070 18PF
26
C1029 T2A 3101051010030 100PF
27
C1030 T3B 3101051000030 10PF
28
C1031 T2A 3101051010030 100PF
29
C1033 T3B 3101051800070 18PF
30
C1034 T3B 3199052290000 2.2PF
31
C1035 T3B 3101051030020 0.01UF
32
C1036 T3B 3101051030020 0.01UF
33
C1038 B2C 3101051030020 0.01UF
34
C1039 B2C 3101051030020 0.01UF
35
C1040 T2A 3101050100101 1.1PF
36
C1041 T3A 3101051510000 150PF
37
C1042 T3A 3101051510000 150PF
38
C1043 T3A 3101051510000 150PF
39
C1044 B2C 3101051010030 100PF
40
C1045 T3B 3101051020010 1000PF
41
C1046 T3B 3101051000020 10PF
76
