Parts List 1
No. Part No. Description Qty.
1 7102006000100 Machine screw (RoHS) 4
2 6300069001000 Magnesium shielding case (RoHS) 1
3 410P5801000H0 PCB for main board (RoHS) 1
4 7500325000000 Heat sink pad for PA (RoHS) 1
5 7300051000010 Metal dome for PTT (RoHS) 1
6 13000P5800090 Semi-finished FPC for PTT (RoHS) 1
7 7102007020020 Self-tapping screw (RoHS) 2
8 6100316000000 O-ring (RoHS)
9 7209004500010 Antenna nut (RoHS) 1
10 4400000050000 SMA RF connector (RoHS) 1
11 6300072001000 Magnesium middle case (RoHS) 1
12 13000P5800070 Semi-finished FPC for MIC (RoHS) 1
13 7102004020100 Self-tapping screw (RoHS) 4
14 13000P5800050 Semi-finished MMI board (RoHS) 1
15 5002120000070 Microphone (RoHS) 1
16 6100111000010 Silicone rubber MIC cover (RoHS) 1
17 7500363000000 PORON pad for simplex MIC (RoHS) 1
18 5005020000030 Receiver (RoHS) 1
19 6100382000000 Silicone rubber cover for receiver (RoHS) 1
20 6000791000010 LCD bracket (RoHS) 1
21 5130000000020
TFT LCD(RoHS)
1
22 7500310000000 PORON pad for LCD (RoHS) 1
23 6000790000000 Encoder knob (RoHS) 1
24 6201739000000 Inner lining for knob (RoHS) 1
25 7207003700000 Nut (RoHS) 1
26 1520P58000100 Front case kit (RoHS) 1
27 860P580600100 Label (RoHS) 1
