No. Part No. Description Qty.
28 6201808100000 Special shape washer (RoHS) 1
29 6001277000000 Accessory jack cover (RoHS) 1
30 7102802010310 UK screw (RoHS) 1
31 7102004001100 Machine screw (RoHS) 2
32 7500367000000 PORON pad for PTT (RoHS) 1
33 6201677000000 PTT bracket (RoHS) 1
34 5402000000100 Motor (RoHS) 1
35 7500328000000 Board-to-board connector for earpiece (RoHS) 1
36 6100334000000 O-ring for encoder switch (RoHS) 1
37 4316030000020 Encoder switch (RoHS) 1
38 13000P5800080 Semi-finished FPC for encoder switch (RoHS) 1
39 6000783000000 Rear cover (RoHS) 1
40 6300071001000 Magnesium rear case (RoHS) 1
41 7103006004000 Machine screw (RoHS) 2
42 7400284000000 Waterproof and dustproof breathable film (RoHS) 1
43 6100383000000 Waterproof ring for battery connector (RoHS) 1
44 6000792100000 SIM card cover (RoHS) 1
45 7400282000000 Insulation sheet for SIM card (RoHS) 1
46 7102012000100 Machine screw (RoHS) 4
47 6100527100000 Waterproof ring for machine screw (RoHS) 4
48 6100384000000 Waterproof O-ring for terminal (RoHS) 1
