Hytera PT580 - Page 86

Service Manual
No. Ref. No. Print No. Part No. Description
350
C6518 T4A 3101071060010 10UF
351
C6519 T3B 3101071060010 10UF
352
C6520 B3B 3199056890000 6.8PF
353
C6521 T4A 3101054740020 0.47UF
354
C6522 T3B 3101054740020 0.47UF
355
C6523 T4A 3101071060010 10UF
356
C6524 T3A 3101071060010 10UF
357
C6525 B3A 3101071060010 10UF
358
C6526 B3B 3101071060010 10UF
359
C6527 B3A 3101051030020 0.01UF
360
C6528 B3A 3101051030020 0.01UF
361
C6529 B3A 3101051030020 0.01UF
362
C6530 B3B 3101051030020 0.01UF
363
C6531 B3A 3101051030020 0.01UF
364
C6532 T4A 3101051030020 0.01UF
365
C6533 T3B 3101051030020 0.01UF
366
D1001 T3B 3304010400000 Varactor
367
D1002 B2C 3304010400000 Varactor
368
D1003 B2C 3304010100990 Varactor
369
D1004 B3C 3304010100200 Varactor
370
D1005 B3C 3304010100200 Varactor
371
D1006 B3C 3304010100200 Varactor
372
D1007 B3C 3304010100200 Varactor
373
D2301 B6A 3304290100000 Varactor
374
D2302 B6A 3304290100000 Varactor
375
D2303 B5A 3301040400000 Schottky barrier diode
376
D2501 T7C 3303990000010 Switching diode
377
D2502 T6C 3399040600010 ESD protection diode
378
D5001 B1B 3399990000260 Rectifier diode
379
D6001 T5B 3399040600000 ESD protection diode
380
D6002 T5C 3399040600000 ESD protection diode
381
D6003 T5C 3399040600000 ESD protection diode
382
F2501 T6C 4010000000000 Resumable fuse
383
G2301 B5A 3110997090000 Super capacitor
384
J2502 B4A 5201070000000 Board-to-board connector
385
J2503 T6C 5208000200120 Socket
386
J4103 T1A 6201676000000 Antenna spring plate
387
J6001 T5B 5205004200010 Battery connector
388
L1001 T3B 3217106781000 780nH
389
L1002 T3B 3217112470010 47nH
390
L1003 T4B 3217105569010 5.6nH
391
L1004 B2C 3217106121000 120nH
392
L1005 B2C 3217106829000 8.2nH
393
L1006 T3A 3217136269000 2.6nH
84
