Hytera PT580 - Page 89

Service Manual
No. Ref. No. Print No. Part No. Description
482
Q2502 T7C 3505010000210 P-MOSFET
483
Q2503 B7A 3505010000210 P-MOSFET
484
Q4101 T1B 3403008000140 BRT
485
Q5001 T2B 3408004000000 NPN transistor
486
Q6001 T4C 3403008000140 BRT
487
Q6501 T4B 3499000000150 Compound transistor
488
Q6502 T4B 3499000000150 Compound transistor
489
Q6503 T3A 3499000000150 Compound transistor
490
Q6504 T3A 3499000000150 Compound transistor
491
Q6505 T4A 3404001000020 NPN transistor
492
Q6506 T3B 3404001000020 NPN transistor
493
R1001 T4A 3001051800010 18Ω
494
R1002 T4A 3001051800010 18Ω
495
R1003 T4A 3001051800010 18Ω
496
R1004 T4A 3001051800010 18Ω
497
R1005 T3B 3001051810010 180Ω
498
R1006 B2C 3212105101000 100nH
499
R1007 B2C 3001051010040 100Ω
500
R1008 T2A 3001055100020 51Ω
501
R1009 T3A 3001051010040 100Ω
502
R1011 T4B 3001051030050 10KΩ
503
R1012 T3A 3001051810010 180Ω
504
R1013 T4B 3001051530010 15KΩ
505
R1014 T3A 3001051810010 180Ω
506
R1015 T3B 3001052230000 22KΩ
507
R1017 T3B 3001058220010 8.2KΩ
508
R1018 T3B 3001051030050 10KΩ
509
R1019 T3B 3001050000000 0Ω
510
R1020 T4B 3001051010040 100Ω
511
R1021 B2C 3001053310000 330Ω
512
R1022 T3A 3001053010010 300Ω
513
R1023 T3A 3001051800010 18Ω
514
R1024 T3A 3001053010010 300Ω
515
R1025 B4C 3001051510010 150Ω
516
R1026 B4C 3001051510010 150Ω
517
R1027 B4C 3001053900010 39Ω
518
R1028 T3A 3001051220000 1.2KΩ
519
R1029 T3A 3001051520010 1.5KΩ
520
R1030 B2C 3001058220010 8.2KΩ
521
R1032 B3C 3001051210010 120Ω
522
R1033 B2C 3001051010040 100Ω
523
R1034 T2A 3001057520000 7.5KΩ
524
R1035 B2C 3001052220010 2.2KΩ
525
R1036 T2A 3001055100020 51Ω
87
