Hytera PT580 - Page 95

Service Manual
No. Ref. No. Print No. Part No. Description
746
R6005 T4C 3001051030050 10KΩ
747
R6006 T4C 3001051030050 10KΩ
748
R6008 B7A 3001050000000 0Ω
749
R6010 T4C 3001051240010 120KΩ
750
R6014 T4C 3001051030050 10KΩ
751
R6015 T4C 3001051030050 10KΩ
752
R6023 B5A 3001050000000 0Ω
753
R6025 B5A 3001051030050 10KΩ
754
R6027 B5A 3001050000000 0Ω
755
R6028 T7C 3001051030050 10KΩ
756
R6501 B3A 3001054740010 470KΩ
757
R6502 B3A 3001051040000 100KΩ
758
R6503 B3B 3001051040000 100KΩ
759
R6504 B3A 3001055690000 5.6Ω
760
R6505 B3B 3001053940010 390KΩ
761
R6506 T4A 3001052020020 2KΩ
762
R6507 T3B 3001052020020 2KΩ
763
T4001 B3B 5406000000050 Transformer
764
T4002 B1B 5406000000100 RF transformer
765
T4003 B2B 5406000000100 RF transformer
766
U1001 T4A 3604026006040 PLL
767
U1002 T2A 3601003000000 RF PA module
768
U2001 T6A 3610010000010 MCU
769
U2002 T7B 3617023000000 Logic IC
770
U2003 T7B 3612002000020 Memory
771
U2004 T7A 3612044000010 Memory
772
U2101 B5C 3613005000020 Baseband processor
773
U2102 B5C 3605026002710 Operational amplifier
774
U2301 T5A 3617023000000 Logic IC
775
U2302 B6A 3617023000000 Logic IC
776
U2303 B6A 3617023000000 Logic IC
777
U2306 T6C 3609006006030 Real-time clock
778
U2401 T7C 3607096000030 Programmable logic part
779
U2501 B7A 3609120000000 Acceleration sensor
780
U4001 B2B 3609005000000 Cartesian IC
781
U4002 T3C 3601095000070 RF PA module
782
U4102 T2C 3601039000010 RF PA module
783
U4103 T1C 3616064000000 Switch IC
784
U4107 B1B 3623089000000 Power detector
785
U5001 B1B 3601039000020 RF amplifier
786
U5002 B1C 3911500600000 Mixer
787
U5003 T2B 3608023000010 Power management IC
788
U5005 B4C 3911050600000 Demodulator
789
U5006 T2A 3601003000000 RF PA module
93
