Procedure
1. If the hose couplings are dirty, clean
them with a lint-free cloth.
2. Fully tighten the couplings.
3. Manually tighten the hose
couplings. Do not use pliers.
4.1.3 Disconnecting the pneumatic hoses
Warning:
• Make sure that the system is depressurized.
Procedure
1. Disconnect the pneumatic hose
from the FRL and the tool.
2. Disconnect the supply hose from
the air supply and the FRL.
3. Roll up the pneumatic hoses and
connect the hose couplings to
prevent them from becoming soiled.
4.2 Connecting the air supply
Warning:
• When you operate the tool in areas with explosion hazard, use nitrogen
instead of air. Contact your local HYTORC representative for more
information.
Installation
47 - 001 - 19
