Hytorc jGun Series - Jgun J-8; Dual Speed

10.1.7 jGun J-8
Drive 1 1/2"
Radius (R) 38.1 mm 1.50"
Length (L) 353.1 mm 13.90"
Height (H) 214.9 mm 8.46"
Width (W) 107.4 mm 4.23"
Weight 13.75 kg 30.32 lbs.
Minimum torque 2,475 Nm 1,825 ft.lbs.
Maximum torque 10,711 Nm 7,900 ft.lbs.
Rpm 1.5
10.2 Dual Speed
R
LW
H
10.2.1 jGun DSP-.5
Drive
3/4"
Radius (R) 31.8 mm 1.25"
Length (L) 254.7 mm 10.03"
Height (H) 188.0 mm 7.40"
Width (W) 75.9 mm 2.99"
Weight 4.1 kg 9.0 lbs.
Minimum torque 109 Nm 80 ft.lbs.
Maximum torque 521 Nm 385 ft.lbs.
Rundown rpm 420
Final torque rpm 24
Technical data
42 47 - 001 -
