Procedure
1. Place the socket over the nut as far
as possible.
2. Place the reaction arm as shown.
3. Place the tool as shown.
5.7.2 Adjustable length
The length of the reaction arm is adjustable. One standard heavy-duty socket must be
used together with the reaction arm.
Procedure
1. Loosen the lock nut.
2. Place the socket over the nut as far
as possible.
3. Tighten the lock nut.
4. Place the reaction arm as shown.
5. Place the tool as shown.
5.8 Straight dual-tool interconnect reaction arm
The length of the reaction arm is adjustable. Two standard heavy-duty sockets must be
used together with the reaction arm.
+\GUDXOLF (OHFWULF 3QHXPDWLF
+\GUDXOLF (OHFWULF 3QHXPDWLF
Reaction arms
47 - 001 - 25
