Hytorc jGun Series User Manual

Procedure
1. For the lowest reaction force,
choose a reaction point as far away
as possible.
2. Place the reaction arm as shown.
3. Place the sockets over the nuts as
far as possible.
4. Place the tools as shown.
5.9 U-shaped dual-tool interconnect reaction arm
The length of the reaction arm is adjustable. Two standard heavy-duty sockets must be
used together with the reaction arm.
Procedure
1. For the lowest reaction force,
choose a reaction point as far away
as possible.
2. Place the reaction arm as shown.
3. Place the sockets over the nuts as
far as possible.
4. Place the tools as shown.
5.10 Multi-tool interconnect reaction arm
Multiple standard heavy-duty sockets must be used together with the reaction arm.
+\GUDXOLF (OHFWULF 3QHXPDWLF
+\GUDXOLF (OHFWULF 3QHXPDWLF
Reaction arms
26 47 - 001 -
