Hytorc jGun Series - Jgun DSP-8; Nut Runner; Jgun J-A1-AP-WG

Maximum torque 7,050 Nm 5,200 ft.lbs.
Rundown rpm 38
Final torque rpm 2.5
10.2.6 jGun DSP-8
Drive 1 1/2"
Radius (R) 62.0 mm 2.44"
Length (L) 390.6 mm 15.38"
Height (H) 214.9 mm 8.46"
Width (W) 115.8 mm 4.56"
Weight 13.4 kg 28.8 lbs.
Minimum torque 2,170 Nm 1,600 ft.lbs.
Maximum torque 11,253 Nm 8,300 ft.lbs.
Rundown rpm 35
Final torque rpm 1.5
10.3 Nut Runner
R
LW
H
10.3.1 jGun J-A1-AP-WG
Drive
3/4"
Radius (R) 38.1 mm 1.50"
Length (L) 284.7 mm 11.21"
Height (H) 195.0 mm 7.70"
Width (W) 86.9 mm 3.42"
Weight 5.4 kg 12.00 lbs.
Minimum torque 346 Nm 255 ft.lbs.
Technical data
44 47 - 001 -
