Hytorc jGun Series - Straight TPF reaction arm

Procedure
1. Place the socket over the nut as far
as possible.
2. Place the reaction arm as shown.
3. Adjust the reaction arm as close to
the flange surface as possible.
4. Place the tool as shown.
5.3 Straight TPF reaction arm
The length of the reaction arm is adjustable. Two standard heavy-duty sockets must be
used together with the reaction arm.
Procedure
1. Place the sockets over the nuts as
far as possible.
2. Place the reaction arm as shown.
3. For the lowest reaction force,
choose a reaction point as far away
as possible.
4. Make sure that the reaction socket
used is placed over the reaction
point completely.
5. Place the tool as shown.
6. For more convenience, place the
safety handle as shown.

+\GUDXOLF (OHFWULF 3QHXPDWLF
+\GUDXOLF (OHFWULF 3QHXPDWLF
Reaction arms
22 47 - 001 -
