Maximum torque 1457 Nm 1,075 ft.lbs.
Rundown rpm 322
Final torque rpm 17
10.3.2 jGun A1-Z
Drive 3/4"
Radius (R) 50.0 mm 1.98"
Length (L) 303.0 mm 11.92"
Height (H) 241.0 mm 9.47"
Width (W) 84.0 mm 3.29"
Weight 6.9 kg 15.18 lbs.
Minimum torque 407 Nm 300 ft.lbs.
Maximum torque 1627 Nm 1,200 ft.lbs.
Rundown rpm 4000
Final torque rpm 7
10.4 Physical conditions
Ambient temperature
0 - 45 °C (0 - 113 °F)
Relative humidity 30% - 95%, non-condensing
Maximum altitude 1,000 m (3,200 ft) above sea level
Lighting normal ambient lighting
Note: The tool is not suitable for use in explosive environments.
10.5 Maximum torque values (male hex sockets)
Maximum torque (Nm)
Hex size (mm) Hex size (inch) Normal Break
14 1/2 476 517
17 5/8 932 1,020
19 3/4 1,612 1,768
22 2,500 2,775
7/8 2,557 2,808
24 2,950 3,600
1 3,822 4,216
27 4,000 4,800
1 1/8 5,440 5,984
32 1 1/4 7,480 8,296
36 1 3/8 9,928 10,880
1 1/2 12,920 14,144
41 1 5/8 16,320 17,952
Technical data
47 - 001 - 45
