5.6 Curved reaction arm with dual-end reaction cup
The length of the reaction arm is fixed.
Procedure
1. Place the socket over the nut as far
as possible.
2. Place the reaction arm as shown.
3. Make sure that the reaction cups
are placed over the reaction points
completely.
4. Place the tool as shown.
5.7 Reaction arm for recessed installation
5.7.1 Fixed length
The length of the reaction arm is fixed. One standard heavy-duty socket must be used
together with the reaction arm.
+\GUDXOLF (OHFWULF 3QHXPDWLF
Reaction arms
24 47 - 001 -
