Hytorc jGun Series - 10 Technical Data; Single Speed; Jgun J-.25; Jgun J-.5

10 Technical data
10.1 Single Speed
R
LW
H
10.1.1 jGun J-.25
Drive
3/4"
Radius (R) 31.8 mm 1.25"
Length (L) 181.6 mm 7.15"
Height (H) 179.3 mm 7.06"
Width (W) 69.1 mm 2.72"
Weight 3.3 kg 7.2 lbs.
Minimum torque 68 Nm 50 ft.lbs.
Maximum torque 338 Nm 250 ft.lbs.
Rpm 65
10.1.2 jGun J-.5
Drive
3/4"
Radius (R) 31.8 mm 1.25"
Length (L) 204.9 mm 8.07"
Height (H) 185.9 mm 7.32"
Width (W) 69.6 mm 2.74"
Weight 3.3 kg 7.2 lbs.
Minimum torque 183 Nm 135 ft.lbs.
Maximum torque 678 Nm 500 ft.lbs.
Rpm 24
Technical data
40 47 - 001 -
