SAN Volume Controller 2145-8F4 and SAN Volume Controller 2145-8F2
rear panel indicators
The rear panel indicators for the SAN Volume Controller 2145-8F4 and the SAN
Volume Controller 2145-8F2 are contained on the back panel assembly.
SAN Volume Controller 2145-8F4 rear panel indicators
The following figure shows the rear panel indicators on the SAN Volume
Controller 2145-8F4 back panel assembly.
1
Fibre-channel LEDs
2
Ethernet link LED
3
Power, location, and system error LEDs
4
Ac and dc LEDs
SAN Volume Controller 2145-8F2 rear panel indicators
The following figure shows the rear panel indicators on the SAN Volume
Controller 2145-8F2 back panel assembly.
1
Fibre-channel LEDs
2
Ethernet link LED
3
Power, location, and system error LEDs
4
Ac and dc LEDs
svc00191
1
2
3
4
Figure 40. SAN Volume Controller 2145-8F4 rear panel
svc00089
1
3
4
2
Figure 41. SAN Volume Controller 2145-8F2 rear panel
