1
PCI slot 1
2
Fibre-channel port 1
3
Fibre-channel port 2
4
Fibre-channel port 3
5
Fibre-channel port 4
6
PCI slot 2
7
Power supply
8
Serial connection
9
Ethernet port 1
The
following figure shows the type of connector that is located on the power
supply assembly. The connector enables you to connect the SAN Volume Controller
2145-8G4 to the power source from the uninterruptible power supply.
SAN Volume Controller 2145-8G4 ports used during service
procedures
The SAN Volume Controller 2145-8G4 contains a number of ports that are only
used during service procedures. These ports are shown in Figure 5 on page 14.
Ground
Live
Neutral
Chapter 2. SAN Volume Controller overview 13
