the service panel. Go to “FID entry point” on page 6, and use the FID that displayed to analyze the
condition.
The CE Action menus, Figure 50 on page 111 and Figure 51 on page 111, display the result of a
completed action.
CE ACTIONSUCCESSFUL
BACK TOCEMENUS
UNLOADDRIVE
RESET DRIVE...
a14m0145
Figure 50: CE Action Successful display
CE ACTIONFAILED
BACK TOCEMENUS
UNLOADDRIVE
RESET DRIVE...
a14m0146
Figure 51: CE Action Failed display
CE Loop Diag menu
Table 69 on page 111 shows the CE Loop Diag menu items. This menu allows the CE to select tests to run
in loop mode. A looptest runs until you stop that test.
Table 69:
CE Loop Diag menu
Function Next menu
Cancel “CE Verify Fix/Diag menu” on page 108
POST “Status menus” on page 109
Read/Write “Status menus” on page 109
Read/Write (Short) “Status menus” on page 109
Panel “Status menus” on page 109
Test Wrap “Status menus” on page 109
Test Frame Wrap
– Unplug From Silo –
“Status menus” on page 109
Compliance –
Compactor Diag –
Test Fibre Wrap “Test Fibre Wrap menu” on page 112
Note:
1. Supplemental Message Line 1: Please be patient
2. Supplemental Message Line 2: when stopping diag.
Cancel
Causes the CE Verify Fix/Diag menu to display.
Virtual Operator panel
111
