Figure 6: Cleaning cartridge
Leader pin replacement kit
The leader pin replacement kit (P/N 18P8887) is a customer-purchased item. Replacing the leader pin is
the customer's responsibility. Use Table 19 on page 37 with Figure 7 on page 37 to identify the leader
pin replacement kit items.
Table 19: Leader pin replacement kit.
Use with Figure 7 on page 37
Item number Description
1 Leader pin-attach tool
2 Cartridge manual-rewinding tool
3 Leader pins and C-clips
(Not shown) Instructions (refer to the 3592 Operator Guide)
Note: Replacing the leader pin is used only as a temporary measure to retrieve the data from the tape; it
is not a permanent x.
Figure 7: Leader pin replacement kit. Use with Table 19 on page 37
Introduction
37
