CE Ucode Grp
The link level and size of the microcode.
CE DRAM Grp
The EC levels of the module. These elds are maintained only in DRAM, not in flash EPROM or in the
microcode.
CE Flash Grp
The Fibre Channel addresses and the other setup choices you can make from the service panel (the
dynamic information). This information is in flash EPROM.
CE Microcode Traps menu
Note: Use this only when directed by your next level of support.
Table 109 on page 140 shows the CE Microcode Traps menu items. This menu allows the CE to set a
specic trap in microcode to force a microcode dump.
Table 109: CE Microcode Traps menu
Function Next menu
Cancel “CE Utilities menu” on page 138
0
0
0
0
-
Add FSC Trap -
Remove FSC Trap -
List FSC Traps “CE FSC Trap List menu” on page 141
Saved Traps… “CE Saved Traps menu” on page 140
Note:
1. Supplemental Message Line 1: Trap set, Trap removed, or Select FSC
2. Supplemental Message Line 2: <none>
Cancel
Causes “CE Utilities menu” on page 138 to display. Address is not saved.
Trap
Allows CE to select a specic hex value. To change value of nibble, select nibble, which causes menu
to display where you can select ‘0’ to ‘F'.
Add FSC Trap
Allows the CE to add an FSC trap.
Remove FSC Trap
Allows the CE to remove an FSC trap.
List FSC Traps
Causes all FSC traps to be displayed in “CE FSC Trap List menu” on page 141.
Saved Traps…
Causes the “CE Saved Traps menu” on page 140 to display.
CE Saved Traps menu
Note: Use this only when directed by your next level of support.
140
IBM 3592 TS1140, TS1150, TS1155, and TS1160 Tape Drives: Maintenance Information
