Table 107: CE Utilities menu (continued)
Function Next menu
Engr Use Only… “Enter Password menu” on page 144
OEM Use Only… “Enter Password menu” on page 144
Cancel
Causes the “CE Options menu” on page 107 to display.
Calibrate Drive
Allows the CE to calibrate the drive read/write channel to optimum settings for the tape cartridge that
currently is loaded.
Disp Sensors…
Causes the “CE Disp Sensors menu (CE Online Mode)” on page 154 to display, which allows the CE to
exercise sensors in the device and observe feedback from the operation.
Disp/Alt VPD…
Allows the CE to display or change the vital product data (VPD). Changing the VPD must be done only
with assistance from support personnel.
Microcode Trap…
Allows the CE to set a specic FSC trap (error microcode match) in microcode to force a microcode
dump.
Read Tape…
Allows the CE to display a portion of the data on the tape cartridge.
Show Statistics…
Allow the CE to display internal counts of activities.
Engr Use Only…
Password required. Allows support personnel to access selected utilities.
OEM Use Only…
Password required. Allows OEM support personnel to customize VPD data.
CE Disp/Alt VPD menu
Note: Use this only when directed by your next level of support.
Table 108 on page 139
shows the CE Disp/Alt VPD menu items. This menu allows the CE to select the
vital product data (VPD) group that contains the specic VPD eld to be displayed or altered. You can
display all the contents in each of the groups, but can alter some of the contents in only the flash group.
Table 108:
CE Disp/Alt VPD menu
Function Next menu
Cancel “CE Utilities menu” on page 138
CE Ucode Grp CE Ucode Grp menu (not shown)
CE DRAM Grp CE DRAM Grp menu (not shown)
CE Flash Grp CE Flash Grp menu (not shown)
Note:
1. Supplemental Message Line 1: Select VPD eld
2. Supplemental Message Line 2: <none>
Cancel
Causes the “CE Utilities menu” on page 138 to display.
Virtual Operator panel
139
