IBM 3592 User Manual

2
a05m0374
Figure 56: Installing the rail - front
a05m0373
2
10
Figure 57: Installing the rail - rear
3. Set the enclosure ( 3 ) on the rails and fasten with two screws ( 4 ).
4. Insert power supplies ( 5 ) into the enclosure. Ensure that the orange tabs are locked. See Figure 80 on
page 252.
5. Insert the drive or drives ( 6 ) into the enclosure.
• If the drives are installed from the front of the enclosure, verify that the rear canister latch is in the
locked position. Tighten the thumbscrew if necessary to hold it in place.
• If the drives are installed from the rear of the enclosure, move the rear canister latch to the vertical
position to unlock it. Insert the drive and lock the rear canister latch by turning the latches to a
horizontal position.
Installation
171
