Table 4: FIDs and FRUs (continued)
Reporte
d FID
FRUs FRU name or description Prob-
ability
Page reference or instruction
FE See 'Reported FID 87' in this table
FF Informational or non-hardware related status or error
- Operator procedural or host
problem
- “FID FF - Operator action or host program error”
on page 245
Attention Drive (ATTN DRV) messages
ATTN DRV message is displayed on the service panel (not from CE Error Log).
1. If ATTN is displayed, press Enter. If a FID appears, go to “FID entry point” on page 6.
2. If no FID is presented, use the ATTN DRV message, and follow the Error Log procedure.
--OR--
ATTN DRV message is from the CE Error Log (“CE Error Log menu” on page 134)
1. Go to “CE Error Log menu” on page 134
and analyze the Error Log for any FIDs with a time stamp close
to the time of the ATTN DRV message. If a FID appears to be associated with the ATTN DRV message,
go to Table 4 on page 7.
2. Error Log does not help identify a FID. Run CE DIAGS (“CE Verify Fix/Diag menu” on page 108 or Test
Drive function).
3. If CE DIAGS does not identify a FID, use the ATTN DRV message and Table 5 on page 11 to nd the
fault.
Table 5:
ATTN DRV messages
ATTN DRV FRUs FRU name or description Prob-
ability
Page reference or instruction
Load Error
1. Ensure that the cartridge is not broken and that the leader pin is attached. See "Damaged
Cartridges" in the 3592 Drive Operator Guide. Have the customer replace the cartridge if it is
damaged.
2. Ensure that the cartridge is a 3592 compatible-type cartridge.
3. Ensure that the cartridge is supported by the drive model.
87 Cartridge 35% “FID 87 or F2 - Isolating fault
between media and hardware” on
page 243
85 Drive canister 60%
• “FID 85: Drive canister” on page
252
Start 11
