395Power Stacker
5. Lift the loose end of the constant force spring and let it curl up on the
outside of the remaining spring and drum. (See Figure 76.)
6. While holding the drum tightly, continue to curl the spring until it is
completely unwound from the drum. (See Figure 76.)
7. To install a new constant force spring, reverse the steps of this
procedure.
Drum
Spring
Figure 76. Removing the Constant Force Spring from the Drum
