To obtain the drive firmware version:
Click on the drive icon in the left pane of the Physical View tab of the Subsystem Management
window. The properties of the drive will be displayed in the right pane of the Physical view tab.
You must perform this step for each individual drive.
To obtain the ESM and drive enclosure component firmware versions:
1. In the left pane of the Physical View tab in the Subsystem Management window, click the
Drive Enclosure Component icon for the enclosure that you want to check the firmware
version. The Drive Enclosure Component Information window opens.
2. Click the ESM icon in the left pane. The ESM information displays in the right pane of the
Drive Enclosure Component Information window.
3. Locate the firmware version of each ESM in the drive enclosure.
Specifications
This section provides site specifications for the storage expansion enclosure. Before installing a storage
expansion enclosure, you must either verify that your planned installation site meets these requirements,
or prepare the site so that it does meet these requirements. Preparations might involve meeting area
requirements, environmental requirements, and electrical requirements for storage expansion enclosure
installation, service, and operation.
Area requirements
The floor space at the installation site must provide enough strength to support the weight of the storage
subsystem and associated equipment; sufficient space to install, operate, and service the storage
subsystem; and sufficient ventilation to provide a free flow of air to the unit.
Dimensions
The DCS3700 conforms to the 19-inch rack standard. Table 3 shows the dimensions of the DCS3700, with
all components installed including the bezel.
Table 3. DCS3700 storage expansion enclosure dimensions
Height Width Depth
1
6.93 in. (17.6 cm) 19 in. (48.3 cm) 34.1 in. (86.6 cm)
1
Enclosure full depth including a cable bend radius of 2.7 inches is 36.8 inches (93.5 cm).
Weight
The total weight of the storage enclosure depends on the configuration of the unit. Table 4 lists the
maximum, empty, and shipping weights for the DCS3700 in different configurations. Table 5 on page 18
lists the weight of each component.
Table 4. DCS3700 weights
Unit
Weight
Maximum
1
Empty
2
Shipping
3
DCS3700 storage system 102.1 kg (225.2 lb) 57.5 kg (126.8 lb) 100 kg (220 lb)
DCS3700 expansion unit 101.0 kg (222.6 lb) 56.3 kg (124.2 lb)
1
Chassis with all FRUs and 60 drives.
2
Chassis without drives but with midplane and all FRUs.
3
Includes the DCS3700, support rails, power cords, publications, 20 drives, shipping material, and the pallet.
Chapter 1. Introduction 17
