Table 5. DCS3700 component weights
Unit Weight
DCS3700 storage expansion enclosure with midplane only
(all FRUs removed)
19.5 kg (43 lb)
Drive drawer (includes cable chains but no drives) 5.2 kg (11.5 lb)
3.5in Disk drive module 0.7 kg (1.6 lb)
Power supply 2.5 kg (5.5 lb)
Fan assembly 1.1 kg (2.4 lb)
ESM 1.5 kg (3.4 lb)
Controller with cache battery backup, no HIC 2.0 kg (4.5 lb)
Shipping dimensions
The DCS3700 is shipped on a pallet. Table 6 lists shipping carton dimensions.
Table 6. DCS3700 shipping carton dimensions
Width Depth Height
1
24 in. (61 cm) 39.75 in. (101 cm) 29.5 in. (74.9 cm)
1
The height shown includes the height of the pallet.
Environmental requirements and specifications
This section describes the environmental requirements and specifications for the storage expansion
enclosure, including temperature and humidity, altitude, airflow and heat dissipation, shock and
vibration requirements, and acoustic noise levels.
Temperature and humidity
Table 7 lists the acceptable temperature and humidity ranges for the DCS3700 storage expansion
enclosure when in storage or in transit.
Note: Substantial deviations from the suggested operating range, in either direction, if sustained for
extended periods of time, will expose the unit to greater risk of failure from external causes.
Table 7. Temperature and humidity requirements for storage expansion enclosure when in storage or in transit
Condition Parameter Requirement
Temperature Operating range 10° - 35° C (50° - 95° F)
Maximum rate of change 10° C (18° F) per hour
Storage range -10° - 65° C (14° - 149° F)
Maximum rate of change 15° C (27° F) per hour
Transit range -40° C to 65° C (-40° F to 149° F)
Maximum rate of change 20° C (36° F) per hour
Relative humidity (no condensation) Operating range 20% to 80%
Storage range 10% to 90%
Transit range 5% to 95%
Maximum dew point 26° C (79° F)
Maximum gradient 10% per hour
18 IBM System Storage DCS3700: Installation, User, and Maintenance Guide
