v After you replace the battery, you must reconfigure the server and reset the
system date and time.
v To avoid possible danger, read and follow the following safety statement.
Statement 2:
CAUTION:
When replacing the lithium battery, use only IBM Part Number 33F8354 or an
equivalent type battery recommended by the manufacturer. If your system has
a module containing a lithium battery, replace it only with the same module
type made by the same manufacturer. The battery contains lithium and can
explode if not properly used, handled, or disposed of.
Do not:
v Throw or immerse into water
v Heat to more than 100°C (212°F)
v Repair or disassemble
Dispose of the battery as required by local ordinances or regulations.
To install the replacement battery on 4U server models with non-hot-swap power
supplies, complete the following steps. For the 5U server model with hot-swap
power supplies (Model name: 2582-F4x), please see the next sub-section.
1. Follow any special handling and installation instructions that come with the
replacement battery.
2. Insert the battery:
a. Hold the battery in a vertical orientation so that the smaller side is facing the
socket.
b. Tilt the battery and slide the battery into its socket; then, press the battery
toward the socket until it clicks into place. Make sure that the battery clip
holds the battery securely.
3. Install the air duct.
4. Install the side cover (see “Installing the side cover” on page 167).
5. Stand the server back up in its vertical position.
6. Reconnect the external cables and power cords; then, turn on the attached
devices and turn on the server.
7. Start the Configuration/Setup Utility program and reset the configuration:
v Set the system date and time.
v Set the power-on password.
v Reconfigure the server.
210 IBM System x3100 M4 Type 2582: Problem Determination and Service Guide
