Connections From 4 Channel Relay Board (Option Module)
CN4 Output Relay Connections (i606)
1 RL 1 Common
2 RL 1 Normally Closed
3 RL 1 Normally Open
4 RL 2 Common
5 RL 2 Normally Closed
6 RL 2 Normally Open
7 RL 3 Common
8 RL 3 Normally Closed
9 RL 3 Normally Open
10 RL 4 Common
11 RL 4 Normally Closed
12 RL 4 Normally Open
7x0.2 - 6Amp (24 AWG) Cable
Note : Maximum relay contact rating =2 Amp @ 30v DC
See Section 3.5.1 for full operational details
Connections To/From Suppression Board (Option Module)
CN5 Input/Output Connections (i623)
1 RL1 O/P - Solenoid 1 +ve
2 RL1 O/P - Solenoid 1 -ve
3 RL2 O/P - Solenoid 2 +ve
4 RL2 O/P - Solenoid 2 -ve
5 RL3 O/P - Alarm 1 +ve
6 RL3 O/P - Alarm 1 -ve
7 RL4 O/P - Alarm 2 +ve
8 RL4 O/P - Alarm 2 -ve
9 Pressure Switch 1 +ve (I/P)
10 Pressure Switch 1 -ve (I/P)
11 Pressure Switch 2 +ve (I/P)
12 Pressure Switch 2 -ve (I/P)
13 Call Point 1 +ve (I/P)
14 Call Point 1 -ve (I/P)
15 Call Point 2 +ve (I/P)
16 Call Point 2 -ve (I/P)
Relay RL1 to RL4 outputs – (fused at 2Amp) 7x0.2 - 6Amp
(24 AWG) Cable
Pressure Switch and Call Point inputs –
7x0.2 - 6Amp (24 AWG) Cable
See Section 3.5.4 for full operational details
Connections From Current Output Board (Option Module)
CN2 Output Connections (i624)
1 Output 1 +ve
2 Output 1 -ve
3 Output 2 +ve
4 Output 2 -ve
5 Output 3 +ve
6 Output 3 -ve
7 Output 4 +ve
8 Output 4 -ve
9 Output 5 +ve
10 Output 5 -ve
11 Output 6 +ve
12 Output 6 -ve
13 Output 7 +ve
14 Output 7 -ve
15 Output 8 +ve
16 Output 8 -ve
All Outputs : -
Maximum output voltage = 20v
Output current = 4 – 20mA (optional 0 – 20 mA)
7x0.2 - 6Amp (24 AWG) Cable
See Section 3.5.2 for full operational details
