■ Scan types
The transceiver has 4 scan types, a Tag function and 4
Resume options, for scanning versatility.
Repeatedly scans all Tag channels in sequence.
ch 40
ch 1 ch 2 ch 3
ch 4
ch 5
ch 6ch 39
OPEN SCAN
���
��
�
Repeatedly checks a designated Priority channel
after scanning 5 tagged channels.
Priority
channel
GROUP OR PRIORITY SCAN
ch 1
ch 2 ch 3 ch 4
ch 5
ch 10
ch 9 ch 8 ch 7
ch 6
���
���
��
��
Tag channels are independently set for Open, Group and
Priority scans. All channels may be preset as tag channels
for all scans.
RPT02
RPT02RPT01
Scan cancel
RPT48
RPT01
RPT03RPT04
RPT48
���
�
���
�
REPEATER SEARCH SCAN
Scans all Repeater channels (‘RPT01’ to ‘RPT08’ and
‘RPT41’ to ‘RPT48’)* in sequence. If there are no busy
channels after scanning channels ‘RPT01’ to ‘RPT08’ and
‘RPT41’ to ‘RPT48,’* the scan begins from ‘RPT01’ again,
and then the transceiver transmits a signal to search for a
repeater while scanning.
* Excludes Emergency Repeater ‘RPT05.’
