Icom IC-718 - Screen

N Saving a voice message into the USB-Memory
D Saving the received audio memory
The recorded RX memory contents can be saved into
the USB-Memory.
q During voice recorder RX memory screen display,
push [SAVE] (F-5) to select voice file save screen.
• Previously selected screen, TX or RX memory, is dis-
played. If the TX message (T1–T4) appears, push [T/
R] (F-6)
to select RX message.
w Change the following conditions if desired.
• File name:
z Push [EDIT] (F-4) to select file name edit con-
dition.
• Push [DIR/FILE] (F-1) several times to select the
file name, if necessary.
x Push [ABC] (MF6), [123] (MF7) or [Symbol]
(MF7) to select the character group, then rotate
the main dial to select the character.
• [ABC] (MF6) : A to Z (capital letters); [123] (MF7): 0
to 9 (numerals); [Symbol]
(MF7): ! # $ % & ’ ` ^ – (
) { } _
~
@ can be selected.
• Push [
Ω] (F-1)
to move the cursor left, push [≈]
(F-2)
to move the cursor right, push [DEL] (F-3)
to delete a character and push [SPACE] (F-4) to
insert a space.
c Push [EXIT/SET] to set the file name.
• Saving location
z Push [DIR/FILE] (F-1) to select tree view
screen.
x Select the desired directory or folder in the
USB-Memory.
• Push [Ω ≈] (F-4) to select the upper directory.
• Push [
Y] (F-2)
or [Z] (F-3) to select folder in the
same directory.
• Push and hold [
Ω ≈] (F-4)
for 1 sec. to select a
folder in the directory.
• Push [REN] (MF5)
to rename the folder.
• Push and hold [DEL] (MF6)
for 1 sec. to delete
the folder.
• Push and hold [MAKE] (F-6)
for 1 sec. to making
a new folder. (Edit the name with the same man-
ner as the “• File name” above.)
c Push [DIR/FILE] (F-1) twice to select the file
name.
e Push [SAVE] (F-6).
• After the saving is completed, return to voice recorder
RX memory screen automatically.
D Saving the TX memory
The TX memory contents can also be saved into the
USB-Memory. However, the contents are saved with
the message list, set mode conditions, etc. at the
same time. See
page ?? for details.
The USB-Memory is not supplied by Icom.
F-1 F-4
EXIT/SET
Main dial
EDITDIR/FILE SAVE
F-5
• Voice recorder RX memory screen
• Voice file save screen— file name edit
• While saving
When a PC keyboard is connected to [USB] con-
nector on the front panel, the file name can also be
edited from the keyboard. In this case, an USB hub
is required.
98
5
VOICE RECORDER FUNCTIONS
