Icom IC-718 - D Data Content Description; Operating Mode

D Data content description
• Operating frequency
Command : 00, 03, 05
q
XXXXX
we
X
rt
XX00
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (Fixed) 100 MHz digit: 0 (Fixed)
• Operating mode
Command : 04
q
XXXX
w
q Operating mode w Filter setting
00: LSB 05: FM 01: WIDE
01: USB 07: CW-R 02: MID
02: AM 08: RTTY-R 03: NAR
03: CW 12: PSK
04: RTTY 13: PSK-R
• Memory keyer contents
Command : 1A 02
X
q: Channel data
01：M1
02：M2
03：M3
04：M4
w–&1: Text data
XXX
……
XX
• Character’s code
Character ASCII code Description
0–9 30–39 Numerals
A–Z 41–5A Alphabetical characters
space 20 Word space
/ 2F Symbol
? 3F Symbol
, 2C Symbol
. 2E Symbol
@ 40 Symbol
^ 5E e.g., to send bt, enter 5E 42 54

2A Inserts contest number (can be
used for 1 channel only)
• Band stacking register
Command : 1A 01
q
XXXX
w
• Frequency band code
Code Freq. band Frequency range (unit: MHz)
1 1.8 1.800000– 1.999999
2 3.5 3.400000– 4.099999
3 7 6.900000– 7.499999
4 10 9.900000–10.499999
5 14 13.900000–14.499999
6 18 17.900000–18.499999
7 21 20.900000–21.499999
8 24 24.400000–25.099999
9 28 28.000000–29.999999
10 50 50.000000–54.000000
12 GENE Other than above
• Register code
Code Registered No.
1 1 (latest)
22
3 3 (oldest)
For example, when sending/reading the oldest con-
tents in the 21 MHz band, the code “0703” is used.
• Clock 2 offset time setting
Command : 1A 05 0056
X
Shift direction
00: − (minus)
01: + (plus)
Offset time
0000−2400
XXX XX
• Offset frequency setting
Command : 1A 05 0065, 0066, 0072
1 kHz digit: 0–9 100 Hz digit: 0 (fixed) 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–9
†
1 MHz digit: 0–4 Direction: 00=+ direction 01=– direction
q
0XXXXXX
we
0
r*
*No need to enter for transverter offset frequency setting.
†
Transverter offset only; Fix to ‘0’ for split offset setting.
156
12
CONTROL COMMAND
