• Codes for memory name, opening
message and CLOCK2 name contents
To send or read the desired memory name settings,
the character codes, instructed codes for memory
keyer contents, and follows are used.
• Character’s code— Alphabetical characters
Character ASCII code Character ASCII code
a–z 61–7A — —
• Character’s code— Symbols
Character ASCII code Character ASCII code
!21#23
$24%25
&26¥ 5C
?3F ” 22
’27`60
+2B– 2D
:3A; 3B
=3D< 3C
>3E ( 28
)29[ 5B
]5D{ 7B
}7D| 7C
_5F– 7E
@40
• Color setting
Command : 1A 05 0106, 0107, 0140, 0149, 0150,
0151, 0152, 0154, 0159, 0160,
0161, 0162
1000 100 10 1
q
0XXX0XXX0XXX
werty
1000 100 10 1 1000 100 10 1
R (Red) G (Green) B (Blue)
Using 0000–0255 for each color element.
• Bandscope edge frequency setting
Command : 1A 05 0115, 0116, 0117, 0118, 0119,
0120, 0121, 0122, 0123, 0124,
0125, 0126
1 kHz: 0–9 100 Hz: 0 (fixed) 100 kHz: 0–9 10 kHz: 0–9 10 MHz: 0–6 1 MHz: 0–9 1 kHz: 0–9 100 Hz: 0 (fixed) 100 kHz: 0–9 10 kHz: 0–9 10 MHz: 0–6 1 MHz: 0–9
q
XXXXXXXXXXXX
werty
Lower edge Higher edge
• Data mode with filter width setting
Command : 1A 06
q
XX XX
w
00=Data mode OFF
01=FIL1
02=FIL2
03=FIL3
00=Data mode OFF
01=Data mode 1 (D1)
02=Data mode 2 (D2)
03=Data mode 3 (D3)
• Repeater tone/tone squelch frequency
setting
Command : 1B 00, 01
100Hz digit: 0–2 10 Hz digit: 0–9 1 Hz digit: 0–9 0.1 Hz digit: 0–9 Fixed digit: 0* Fixed digit: 0*
q*
00XXX
we
X
*Not necessary when setting a frequency.
• Band edge frequency setting
Command 02, 1E 01, 03
q
XXX
wertyuio!0 !1 !2
XXXXXXXXX2DXXXXXXXXXX
10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) 10 Hz digit: 0–9 1 Hz digit: 0–9 1 kHz digit: 0–9 100 Hz digit: 0–9 100 kHz digit: 0–9 10 kHz digit: 0–9 10 MHz digit: 0–6 1 MHz digit: 0–9 1000 MHz digit: 0 (fixed) 100 MHz digit: 0 (fixed) Separater (fixed)
Lower edge Higher edge
Edge numger: 00–30
157
12
