D Command table (continued)
Cmd.
Sub cmd.
Data Description
1A 05 0139 00 RTTY decoder FFT scope averaging func-
tion OFF
01 Number 2 selection for RTTY decoder FFT
scope averaging function
02 Number 3 selection for RTTY decoder FFT
scope averaging function
03 Number 4 selection for RTTY decoder FFT
scope averaging function
0140 see p. 000 Set/read FFT scope waveform color set for
RTTY decoder
0141 00 RTTY decode USOS function OFF
01 RTTY decode USOS function ON
0142 00 “CR,LF,CR+LF” selection for RTTY decode
new line code
01 “CR+LF” selection for RTTY decode new
line code
0143 00 OFF selection for RTTY diddle
01 BLANK selection for RTTY diddle
02 LTRS selection for RTTY diddle
0144 00 RTTY encode USOS function OFF
01 RTTY encode USOS function ON
0145 00 RTTY auto CR+LF by keyboard’s [F12] OFF
01 RTTY auto CR+LF by keyboard’s [F12] ON
0146 00 RTTY time stamp OFF
01 RTTY time stamp ON
0147 00 Local time selection for RTTY time stamp
01 Clock2 selection for RTTY time stamp
0148 00 Frequency stamp for RTTY time stamp OFF
01 Frequency stamp for RTTY time stamp ON
0149 see p. 000 Send/read received text font color for RTTY
decoder
0150 see p. 000 Send/read transmitted text font color (RTTY)
0151 see p. 000 Send/read time stamp text font color (RTTY)
0152 see p. 000 Send/read text font color in TX buffer (RTTY)
0153 00 PSK decoder FFT scope averaging func-
tion OFF
01 Number 2 selection for PSK decoder FFT
scope averaging function
02 Number 3 selection for PSK decoder FFT
scope averaging function
03 Number 4 selection for PSK decoder FFT
scope averaging function
0154 see p. 000 Set/read FFT scope waveform color set for
PSK decoder
0155 00 ±8 Hz selection for PSK AFC function tun-
ing range
01 ±15 Hz selection for PSK AFC function tun-
ing range
0156 00 PSK time stamp OFF
01 PSK time stamp ON
0157 00 Local time selection for PSK time stamp
01 Clock2 selection for PSK time stamp
0158 00 Frequency stamp for PSK time stamp OFF
01 Frequency stamp for PSK time stamp ON
0159 see p. 000 Send/read received text font color for PSK
decoder
0160 see p. 000 Send/read transmitted text font color (PSK)
0161 see p. 000 Send/read time stamp text font color (PSK)
0162 see p. 000 Send/read text font color in TX buffer (PSK)
0163 00 LOW scan speed selection
01 HIGH scan speed selection
0164 00 Scan resume OFF
01 Scan resume ON
0165 0000 to
0255
Send/read VOX gain
(0000=0%, 0255=100%)
0166 0000 to
0255
Send/read ANTI-VOX gain
(0000=0%, 0255=100%)
0167 00 to 20 Send/read VOX delay time
(00=0.0 sec., 20=2.0 sec.)
0168 00 VOX voice delay function OFF
01 Short selection for VOX voice delay
02 Mid selection for VOX voice delay
03 Long selection for VOX voice delay
Cmd.
Sub cmd.
Data Description
1A 05 0169 0000 to
0255
Send/read NB level
(0000=0%, 0255=100%)
0170 00 to 09 Send/read NB depth
(00=1, 09=10)
0171 0000 to
0255
Send/read NB width
(0000=1, 0255=100)
0172 0000 to
0255
Send/read MONITOR gain
(0000=0%, 0255=100%)
06 see p. 000 Send/read DATA mode with filter set
07 00 WIDE selection for SSB transmit bandwidth
01 MID selection for SSB transmit bandwidth
02 NAR selection for SSB transmit bandwidth
08 00 SHARP selection for DSP filter type
01 SOFT selection for DSP filter type
09 00 3 kHz roofing filter selection
01 6 kHz roofing filter selection
02 15 kHz roofing filter selection
0A 00 WIDE selection for manual notch width
01 MID selection for manual notch width
02 NAR selection for manual notch width
1B 00 see p. 000 Send/read repeater tone frequency
01 see p. 000 Send/read tone squelch frequency
1C 00 00 Transceiver's condition (RX)
01 Transceiver's condition (TX)
01 00 Antenna tuner OFF (through)
01 Antenna tuner ON
02 Tuning
1E 00
Read number of available TX frequency band
01 see p. 000 Read TX band edge frequencies
02 Read number of user-set TX frequency band
03 see p. 000
Send/read user-set TX band edge frequencies
155
12
CONTROL COMMAND
