D Command table (continued)
Cmd.
Sub cmd.
Data Description
1A 05 0095 00 Voice memory transmission OFF with [F1]–
[F4] on the keyboard
01 Voice memory transmission ON with [F1]–
[F4] on the keyboard
0096 00 Memory keyer transmission OFF with [F1]–
[F4] on the keyboard
01 Memory keyer transmission ON with [F1]–
[F4] on the keyboard
0097 00 CI-V transceive OFF
01 CI-V transceive ON
0098 00 CI-V selection for [USB-B] usage
01 Decode selection for [USB-B] usage
0099 00 300 bps selection for decode speed
01 1200 bps selection for decode speed
02 4800 bps selection for decode speed
03 9600 bps selection for decode speed
04 19200 bps selection for decode speed
0100 00 English keyboard selection
01 Japanese keyboard selection
02 United Kingdom keyboard selection
03 French keyboard selection
04 French (Canadian) keyboard selection
05 German keyboard selection
06 Portuguese keyboard selection
07 Portuguese (Brazilian) keyboard selection
08 Spanish keyboard selection
09 Spanish (Latin American) keyboard selection
10 Italian keyboard selection
0101 0010 to
0100
Send/read keyboard repeat delay
( 0010=100 msec., 0100=1000 msec.;
50 msec. steps)
0102 00 to 31 Send/read keyboard repeat speed
(00=2.0 cps, 31=30.0 cps)
0103 00 Scope indication during TX OFF
01 Scope indication during TX ON
0104 00 Scope max. hold function OFF
01 Scope max. hold function ON
0105 00
Filter center selection for scope center frequency
01 Carrier point center selection for scope cent-
er frequency
02 Carrier point center (Abs. Freq.) selection for
scope center frequency
0106 see p. 000
Send/read waveform color for receiving signal
0107 see p. 000 Send/read waveform color for max. hold
0108 00 SLOW selection for scope sweep speed in
±2.5 kHz span
01 MID selection for scope sweep speed in
±2.5 kHz span
02 FAST selection for scope sweep speed in
±2.5 kHz span
0109 00 SLOW selection for scope sweep speed in
±5 kHz span
01 MID selection for scope sweep speed in
±5 kHz span
02 FAST selection for scope sweep speed in
±5 kHz span
0110 00 SLOW selection for scope sweep speed in
±10 kHz span
01 MID selection for scope sweep speed in
±10 kHz span
02 FAST selection for scope sweep speed in
±10 kHz span
0111 00 SLOW selection for scope sweep speed in
±25 kHz span
01 MID selection for scope sweep speed in
±25 kHz span
02 FAST selection for scope sweep speed in
±25 kHz span
0112 00 SLOW selection for scope sweep speed in
±50 kHz span
01 MID selection for scope sweep speed in
±50 kHz span
02 FAST selection for scope sweep speed in
±50 kHz span
Cmd.
Sub cmd.
Data Description
1A 05 0113 00 SLOW selection for scope sweep speed in
±100 kHz span
01 MID selection for scope sweep speed in
±100 kHz span
02 FAST selection for scope sweep speed in
±100 kHz span
0114 00 SLOW selection for scope sweep speed in
±250 kHz span
01 MID selection for scope sweep speed in
±250 kHz span
02 FAST selection for scope sweep speed in
±250 kHz span
0115 see p. 000 Scope edge frequencies for 0.03 to
1.60 MHz band
0116 see p. 000 Scope edge frequencies for 1.60 MHz to
2.00 MHz band
0117 see p. 000 Scope edge frequencies for 2.00 MHz to
6.00 MHz band
0118 see p. 000 Scope edge frequencies for 6.00 MHz to
8.00 MHz band
0119 see p. 000 Scope edge frequencies for 8.00 MHz to
11.00 MHz band
0120 see p. 000 Scope edge frequencies for 11.00 MHz to
15.00 MHz band
0121 see p. 000 Scope edge frequencies for 15.00 MHz to
20.00 MHz band
0122 see p. 000 Scope edge frequencies for 20.00 MHz to
22.00 MHz band
0123 see p. 000 Scope edge frequencies for 22.00 MHz to
26.00 MHz band
0124 see p. 000 Scope edge frequencies for 26.00 MHz to
30.00 MHz band
0125 see p. 000 Scope edge frequencies for 30.00 MHz to
45.00 MHz band
0126 see p. 000 Scope edge frequencies for 45.00 MHz to
60.00 MHz band
0127 00 Auto monitor function OFF during voice
memory transmission
01 Auto monitor function ON during voice mem-
ory transmission
0128 03 to 10 Send/read voice memory short play time
(03=3 sec., 10=10 sec.)
0129 05 to 15 Send/read voice memory normal record time
(05=5 sec., 15=15 sec.)
0130 00 Normal selection for contest number style
01
“190¡ANO” selection for contest number
style
02
“190¡ANT” selection for contest number
style
03
“90¡NO” selection for contest number style
04
“90¡NT” selection for contest number style
0131 01 M1 selection for count up trigger channel
02 M2 selection for count up trigger channel
03 M3 selection for count up trigger channel
04 M4 selection for count up trigger channel
0132 0001 to
9999
Send/read present number
(0001=1, 9999=9999)
0133 01 to 60 Send/read CW keyer repeat time
(01=1 sec., 60=60 sec.)
0134 28 to 45 Send/read CW keyer dot/dash ratio
(28=1:1:2.8, 45=1:1:4.5)
0135 00 2 msec. selection for rise time
01 4 msec. selection for rise time
02 6 msec. selection for rise time
03 8 msec. selection for rise time
04 10 msec. selection for rise time
0136 00 Normal selection for paddle polarity
01 Reverse selection for paddle polarity
0137 00 Straight selection for keyer type
01 BUG-KEY selection for keyer type
02 ELEC-KEY selection for keyer type
0138 00 Mic. up/down keyer function OFF
01 Mic. up/down keyer function ON
154
12
CONTROL COMMAND
