D Command table (continued)
Cmd.
Sub cmd.
Data Description
15 15 0000 to
0255
Read VD meter
(0152=10, 0181=13, 0212=16)
16 0000 to
0255
Read ID meter
(0000=0, 0097=10, 0241=25)
16 02 00 Preamp OFF
01 Preamp 1 ON
02 Preamp 2 ON
12 00 AGC FAST selection
01 AGC MID selection
02 AGC SLOW selection
22 00 Noise blanker OFF
01 Noise blanker ON
32 00 Audio peak filter OFF
01 Audio peak filter WIDE ON
(320 is selected when SHARP APF is set)
02 Audio peak filter MID ON
(160 is selected when SHARP APF is set)
03 Audio peak filter NAR ON
(80 is selected when SHARP APF is set)
40 00 Noise reduction OFF
01 Noise reduction ON
41 00 Auto notch function OFF
01 Auto notch function ON
42 00 Repeater tone OFF
01 Repeater tone ON
43 00 Tone squelch OFF
01 Tone squelch ON
44 00 Speech compressor OFF
01 Speech compressor ON
45 00 Monitor function OFF
01 Monitor function ON
46 00 VOX function OFF
01 VOX function ON
47 00 BK-IN function OFF
01 SEMI BK-IN function ON
02 Full BK-IN function ON
48 00 Manual notch function OFF
01 Manual notch function ON
4F 00 Twin peak filter OFF
01 Twin peak filter ON
50 00 Dial lock function OFF
01 Dial lock function ON
19 00 Reads the transceiver ID
1A 00 see p. 000 Send/read memory contents
01 see p. 000 Send/read band stacking register contents
02 see p. 000 Send/read memory keyer contents
03 00 to 49 Send/read the selected filter width
( SSB, CW, PSK: 00=50 Hz, 40=3600 Hz;
RTTY: 00=50 Hz, 31=2700 Hz;
AM: 00=200 Hz, 49=10 kHz)
04 00 to 13 Send/read the selected AGC time constant
(00=OFF, 01=0.1/0.3 sec., 13=6.0/8.0 sec.)
05 0001 see p. 000
Send/read HPF/LPF setting for SSB RX audio
0002 00 to 10 Send/read SSB RX Tone (Bass) level
(00=–5, 10=+5)
0003 00 to 10 Send/read SSB RX Tone (Treble) level
(00=–5, 10=+5)
0004 see p. 000 Send/read HPF/LPF setting for AM RX audio
0005 00 to 10 Send/read AM RX tone (Bass) level
(00=–5, 10=+5)
0006 00 to 10 Send/read AM RX Tone (Treble) level
(00=–5, 10=+5)
0007 see p. 000 Send/read HPF/LPF setting for FM RX audio
0008 00 to 10 Send/read FM RX tone (Bass) level
(00=–5, 10=+5)
0009 00 to 10 Send/read FM RX Tone (Treble) level
(00=–5, 10=+5)
0010 see p. 000 Send/read HPF/LPF setting for CW RX audio
0011 see p. 000
Send/read HPF/LPF setting for RTTY RX audio
0012 see p. 000
Send/read HPF/LPF setting for PSK RX audio
0013 00 to 10 Send/read SSB TX Tone (Bass) level
(00=–5, 10=+5)
0014 00 to 10 Send/read SSB TX Tone (Treble) level
(00=–5, 10=+5)
Cmd.
Sub cmd.
Data Description
1A 05 0015 00 to 10 Send/read AM TX Tone (Bass) level
(00=–5, 10=+5)
0016 00 to 10 Send/read AM TX Tone (Treble) level
(00=–5, 10=+5)
0017 00 to 10 Send/read FM TX Tone (Bass) level
(00=–5, 10=+5)
0018 00 to 10 Send/read FM TX Tone (Treble) level
(00=–5, 10=+5)
0019 see p. 000 Send/read SSB TX bandwidth for WIDE
0020 see p. 000 Send/read SSB TX bandwidth for MID.
0021 see p. 000 Send/read SSB TX bandwidth for NARROW
0022 0000 to
0255
Send/read DRIVE gain
(0000=0%, 0255=100%)
0023 0000 to
0255
Send/read speech level
(0000=0%, 0255=100%)
0024 0000 to
0255
Send/read CW side tone level
(0000=0%, 0255=100%)
0025 00 CW side tone gain limit OFF
01 CW side tone gain limit ON
0026 0000 to
0255
Send/read beep gain
(0000=0%, 0255=100%)
0027 00 Beep gain limit OFF
01 Beep gain limit ON
0028 00 Squelch mute effect OFF for audio output
from USB-B connector
01 Squelch mute effect ON for audio output
from USB-B connector
0029 0000 to
0255
Send/read modulation level for audio input to
USB-B connector (0000=0%, 0255=100%)
0030 00 [MIC] selection for MOD input connector dur-
ing DATA OFF
01 [ACC] selection for MOD input connector
during DATA OFF
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA OFF
03 [USB] selection for MOD input connector dur-
ing DATA OFF
0031 00 [MIC] selection for MOD input connector dur-
ing DATA1
01 [ACC] selection for MOD input connector
during DATA1
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA1
03 [USB] selection for MOD input connector dur-
ing DATA1
0032 00 [MIC] selection for MOD input connector dur-
ing DATA2
01 [ACC] selection for MOD input connector
during DATA2
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA2
03 [USB] selection for MOD input connector dur-
ing DATA2
0033 00 [MIC] selection for MOD input connector dur-
ing DATA3
01 [ACC] selection for MOD input connector
during DATA3
02 Both [MIC] and [ACC] selection for MOD
input connector during DATA3
03 [USB] selection for MOD input connector dur-
ing DATA3
0034 00 Lead selection for SEND relay type
01 MOS-FET selection for SEND relay type
0035 00 Auto selection for external meter output
01 S (receiving signal strength) selection for ex-
ternal meter output
02 Po (TX output power) selection for external
meter selection
03 SWR selection for external meter output
04 ALC selection for external meter output
05 COMP selection for external meter output
06 Vd selection for external meter output
07 Id selection for external meter output
0036 0000 to
0255
Send/read external meter output level
(see p. 000)
152
12
CONTROL COMMAND
