5: S PECIAL F UNCTIONS
5-74 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
Programming WindLDR
1. From the WindLDR menu bar, select Configuration > Connection Settings.
The Function Area Settings dialog box is displayed.
2. Select Communication Mode for the connection to use.
Configure the communication mode allocated to a maximum of three connections that can be used as client or server. Each
connection can be set to a different port number. Set connections that are not used to Unused.
3. Select Maintenance Communication Server.
The Maintenance Communication Server dialog box is displayed.
4. Specify the parameters.
Click OK.
This concludes configuring the settings.

IDEC FT1A Series Specifications

General

Programming Software	WindLDR
Type	Programmable Logic Controller (PLC)
Display	LCD (varies by model)
Communication Ports	RS232C/RS485 (built-in), USB (programming), Ethernet (optional)
Dimensions	Varies by model
Weight	Varies by model
Model	FT1A Series
