S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 6-11
6: HMI F UNCTION
Configuring the Slave Number
When the SmartAXIS is stopped, you can configure the slave number used in maintenance communication or Modbus RTU
communication. This cannot be configured while the SmartAXIS is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Configurations with the (up) and (down) buttons and press the (OK) button.
3. Select Function with the (up) and (down) buttons and press the (OK) button.
4. Select Communications with the (up) and (down) buttons and press the (OK) button.
5. Select Slave Number with the (up) and (down) buttons and press the (OK) button.
The port selection screen is displayed.
6. Select Port 2 with the (up) and (down) buttons and press the (OK) button.
For example, change the slave number of the port 2 to 1.
7. Specify 1 with the (up) and (down) buttons and press the (OK) button.
• Selectable slave numbers
The slave numbers that can be selected are as follows.
Port 2 Port 3
0 to 255 0 to 255
Stopped
2012/OCT/10/WED
13:30:40
Run
Edit Program
External Memory
Configurations
Function
Clock
Menu Languages
Backlight
Communications
Message Settings
Slave Number
Port 2:
0
Port 3:
0
Port 2:
1
Port 3:
0
