6: HMI F UNCTION
6-10 S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378
Setting the LCD Backlight ON Time
When the SmartAXIS operation buttons are pressed, the backlight turns on.
After an operation button is pressed and the backlight turns on, the backlight automatically turns off if the operation buttons are
not pressed. On the system menu, you can adjust the time from when the backlight turns on until it turns off.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Configurations with the (up) and (down) buttons and press the (OK) button.
3. Select Backlight with the (up) and (down) buttons and press the (OK) button.
4. Move the cursor with the (left) and (right) buttons.
5. Select the value with the (up) and (down) buttons, and then press the (OK) button to set the backlight ON time.
• Backlight ON time configuration range
The backlight ON time configuration range is as follows.
0 to 65,535 seconds
Notes:
• The default backlight ON time is 10 seconds. The default value can be modified in WindLDR Function Area Settings dialog box. For details,
see "Backlight ON Time" on page 5-57.
• The backlight ON time can be changed by modifying the value of D8074.
• When the backlight ON time is set from the system menu, the value of D8074 is modified.
• The value of D8074 returns to the default value when the battery backup dies.
• If the backlight ON time is 0, the backlight is always on.
Stopped
2012/OCT/10/WED
13:30:40
Run
Edit Program
External Memory
Configurations
Function
Clock
Menu Languages
Backlight
Backlight ON time:
00010 s
Backlight ON time:
00020 s
