S
MART
AXIS P
RO
/L
ITE
U
SER
'
S
M
ANUAL
FT9Y-B1378 6-17
6: HMI F
UNCTION
Writing/Clearing TP (Timer Preset Values) and CP (Counter Preset Values) in the User Program
Writing TP (Timer Preset Values) and CP (Counter Preset Values)
Even if you modify TP (Timer Preset Values) and CP (Counter Preset Values) with Device Monitor mode, those changes are not
written to the user program in the ROM. To write the changed preset values to the ROM, you must stop the SmartAXIS and
confirm the changes. When you modify TP (Timer Preset Values) and CP (Counter Preset Values) and attempt to leave Device
Monitor mode, the message below is displayed.
1. Press the (ESC) button or the (OK) button to display the standard screen.
When TP (timer preset values) and CP (counter preset values) differ from the device values in the ROM, T/C is changed is
displayed on the standard screen.
When the SmartAXIS is running, put it to Stop mode. For the steps to stop the SmartAXIS, see "Switching run/stop" on page 6-7.
2. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
3. Select Edit Program with the (up) and (down) buttons and press the (OK) button.
4. Select T/C Preset Values and press the (OK) button.
5. Select Confirm with the (up) and (down) buttons and press the (OK) button.
The changed preset values are written to the user program in the ROM.
Timer/counter preset
values are changed.
Stopped
T/C is changed
2012/OCT/10/WED
13:30:40
When the SmartAXIS is stopped
When the SmartAXIS is running
Running
T/C is changed
2012/OCT/10/WED
13:30:40
Stopped
T/C is changed
2012/OCT/10/WED
13:30:40
Run
Edit Program
External Memory
Configurations
T/C Change Status:
T/C is changed
Clear
Confirm
To Next Page
