IDEC FT1A Series User Manual

S MART AXIS P RO /L ITE U SER ' S M ANUAL FT9Y-B1378 6-19
6: HMI F UNCTION
Monitoring the SmartAXIS Status
You can check the SmartAXIS system software version, operating status, scan time, and protection status.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select Status Monitor with the (up) and (down) buttons and press the (OK) button.
3. The system version is displayed. Press the (down) button.
4. The scan time is displayed. Press the (down) button.
5. The upload protection status is displayed. Press the (down) button.
6. The download protection status is displayed.
Running
13:30:40
2012/OCT/10/WED
Stopped
2012/OCT/10/WED
13:30:40
When the SmartAXIS is stopped
When the SmartAXIS is running
External Memory
Device Monitor
Program Monitor
Status Monitor
Configurations
Device Monitor
Program Monitor
Status Monitor
When the SmartAXIS is stopped
When the SmartAXIS is running
System Version:
1.00
Run/Stop Status:
Running
System Version:
1.00
Run/Stop Status:
Stopped
When the SmartAXIS is stopped
When the SmartAXIS is running
Scan Time:
Current
㸸ࠉ
2 ms
Maximum
㸸ࠉ
4 ms
Minimum
㸸ࠉ
2 ms
Protection Status:
Read Program:
Prohibited
Protection Status:
Write Program:
Password
