S
MART
AXIS P
RO
/L
ITE
U
SER
'
S
M
ANUAL
FT9Y-B1378 6-23
6: HMI F
UNCTION
Downloading the User Program (Memory Cartridge to SmartAXIS)
You can download the user program in the memory cartridge to the SmartAXIS. This function cannot be used while the SmartAXIS
is running.
1. On the standard screen, press the (ESC) + (OK) buttons.
The system menu is displayed.
2. Select External Memory with the (up) and (down) buttons and press the (OK) button.
3. Select Memory Cartridge with the (up) and (down) buttons and press the (OK) button.
4. Select Cartridge -> PLC with the (up) and (down) buttons and press the (OK) button.
5. If the password is configured, you are prompted to enter the password.
Enter the password with the (up), (down), (left), and (right) buttons and press the (OK) button.
The confirmation screen is displayed.
6. Select Yes with the (down) button and press the (OK) button.
7. The screen below is displayed while the user program is downloaded. When the download is finished, the screen in step 4 is
displayed.
Notes:
• In either of the situations below, the password must be entered.
• The user program on the SmartAXIS has been password protected for program uploads.
• The user program on the memory cartridge has been password protected for program downloads.
• If an invalid password is entered in step 5, the screen below is displayed.
Press the (ESC) button or the (OK) button to return to step 4, and then enter the correct password in step 5.
Stopped
2012/OCT/10/WED
13:30:40
Run
Edit Program
External Memory
Configurations
PLC -
>
Cartridge
Cartridge -
>
PLC
Entering the password is required for the following cases:
- The user program in the SmartAXIS is password-protected against the user program download.
- The user program in the memory cartridge is password-protected against the user program upload.
Do you want to clear
program in PLC?
No
Yes
