FT9Y-B1378 2-5
2: P
RODUCT
S
PECIFICATIONS
DC Power Type
Note 1: Use in environments that satisfy product specifications.
Note 2: UL, c-UL Listed at 0 to +50°C (FT1A Version V110).
Type Number
FT1A-
H12RA, B12RA H24RA, B24RA
H40RKA, H40RSA
B40RKA, B40RSA
H48KA, H48SA
B48KA, B48SA
Normal Operating Conditions
Operating Temperature 0 to +55°C (operating ambient temperature) (Note 2)
Storage Temperature –25 to +70°C (no freezing)
Relative Humidity 10 to 95% (non-condensing, operating and storage humidity)
Pollution Degree 2 (IEC60664-1)
Degree of Protection IP20 (IEC60529)
Corrosion Immunity Atmosphere free from corrosive gases
Altitude
Operation: 0 to 2,000m (0 to 6,565 feet)
Transport: 0 to 3,000m (0 to 9,840 feet)
Installation Location Inside cabinet (Note 1)
Device Class Open equipment
Overvoltage Category II
Vibration Resistance
When mounted on a DIN rail or panel surface:
5 to 8.4Hz amplitude 3.5 mm, 8.4 to 150Hz acceleration 9.8m/s
2
(1G)
2 hours per axis on each of three mutually perpendicular axes
Shock Resistance 147m/s
2
(15G), 11 ms duration, 3 shocks per axis on three mutually perpendicular axes
Power Supply
Rated Power Voltage 24V DC
Allowable Voltage Range 20.4 to 28.8V DC (Including ripple voltage)
Maximum Power Consumption 4.3W 4.8W 7.9W 6.0W
Allowable Momentary Power Interruption 10ms maximum (Rated voltage, PS2)
Dielectric Strength Voltage
Between power/input and FE terminals: 500V AC, 1 minute
Between transistor output and FE terminals: 500V AC, 1 minute
Between relay output and FE terminals: 2,300V AC, 1 minute
Between power/input and transistor output terminals: 500V AC, 1 minute
Between power/input and relay output terminals: 2,300V AC, 1 minute
EMC Immunity IEC/EN 61131-2:2007 compliant
Inrush Current 30A maximum
Ground D-type ground (Class 3 ground)
Grounding Wire UL1007 AWG16
Power Supply Wire UL1015 AWG22, UL1007 AWG18
Effect of Improper Power Supply
Connection
Reverse polarity: No operation, no damage
Improper voltage or frequency: Permanent damage may be caused
Improper lead connection: Permanent damage may be caused
Weight Approx. 190g Approx. 310g Approx. 420g Approx. 380g
